Roofs | Perforated trays 90/500 (α)
System TP90-DK140-Arena
Rw 82 | RA 76 | RA,tr 68
System composition System Characteristics Documents System References
Avis technique RE 2020 CSTB FDES
1 2 3 4 5 6 7 8 9 10 11 12
System composition
  • 1 90/500 perforated tray
  • 2 Absorbent glass wool insulation, 30 mm
  • 3 Rock wool insulation, 100 mm
  • 4 CTBH P5 particle board, 22 mm
  • 5 Mechanically affixed bituminous vapour barrier
  • 6 Acoustic Phonotech Pad and Washer
  • 7 Rock wool insulation, 200 mm, 40 kg/m³
  • 8 Steel post
  • 9 Metal purlin
  • 10 Corrugated steel sheet, 1 mm
  • 11 CTBH P5 particle board, 22 mm
  • 12 PHONOTECH DK140 acoustic panel
System Characteristics
Dimensions
Length
1200 mm
Width
600 mm
Total thickness
1148 mm
Technical
Acoustic reduction
Rw (C; Ctr) = 82 (-6 ; -14) dB
Weight (kg/m²)
101,60
U (W/m².K)
0,07
Documents
Assembly instructions
Certifications
Avis technique RE 2020 CSTB FDES
System References

Arena GSE Reims
